¡@R-TYPE HORIZONTAL WITH TWIN HEADS TYPE

HORIZONTALLY MOUNTED WITH TWIN HEADS TYPE PNEUMATIC RIVETING MACHINE

Item Model ST-480R
Riveting Capacity Solid Rivet 0.5-3¢
Max.Stroke 40 m/m
Max.H.Die-head to bed 120 M/M
Spindle Revolution 1500 RPM
Max.depth 100 m/m
Drive Motor 1/8 HP
pressure used (kg/cm2) 2-7 kg
Adjusting work time 1-6 Sec
Net Weight 180kg
Height of Machine (m/m) 1200
Width (m/m) 400
Length (m/m) 1000
